Back to isiphorCompare spectra

isiphor® RGA 565 100

Yellow wet-coated emitter · nominal peak 565 nm. Also available uncoated as SGA — this and further wavelengths on request.

Phosphor · Green

isiphor® RGA 565 100

Silicate (yellow-green) emitter · Eu2+ · default pump 450 nm

FamilySilicate (yellow-green) · Eu2+Particle sizeD50 16.3 µmCIE 1931 x/y0.449 / 0.537Default pump450 nm

Excitation & emission spectrum · real curve

LED pump
ExcitationEmissionLED pump
Peak emission 565 nmFWHM ≈ 93 nm
400450500550600650700750Wavelength (nm)rel. intensity

Performance profile

EfficiencyQuantum efficiency
Colour puritySpectral fit · FWHM
Thermal stabilityResidual intensity, hot
ReliabilityLifetime · humidity
ExcitabilityAbsorption + overlap with 450 nm pump

Indicative ratings for orientation, based on internal measurements. Absolute values vary between measurement setups.

isiphor® phosphors · Litec-LLL

Interested in RGA 565 100?

Request a sample or the datasheet — or tell us your application and operating conditions.

Request sample / datasheetBack to yellow
